IMX28 / AM335X Based Smart IoT Gateway Development Platform

Smart IoT Gateway Development Platform - An Overview

i.MX6ULL/ i.MX28/ AM335X Based Smart IoT Gateway Development Platform offers a cost-effective processor application which is compatible with DIN (EN 60715) mounting enclosure and belongs to the product family of IoT Gateway and Devices. This module simplifies the process of integration and brings together the building blocks for secure, production- ready IoT systems. It is used to collect, control and transfer collected data (or) information from various components such as: solar power box, smart sensors etc.,

Specifications

CPU

  • Dory CPU IMX6ULL- Supports All Fiamma MAS CPU Dory IMX6ULL with kernel linux 4.9.xx
  • FIAMMA AM335x- Supports All Fiamma MAS CPU Board Family with Kernel 3.14
  • GHITA i.MX28- Supports All Ghita MAS CPU Board Family with Kernel 3.17
  • Display and Touch Panel

  • Display interface- LVDS (optional)
  • Touch Panel-4 wires resistive (optional)
  • Smart panel-Mas smart panel interface (optional)
  • Audio

  • Audio output- Stereo audio Out 1,5W @ 8Ohm coming from the CPU or the 3G module
  • Audio in- Microphone input that is routed to CPU or 3G module
  • Isolated CAN Bus

  • Number of channels-1
  • Protocol- Can 2.0
  • Speed- Up to 1Mbit/s (depending on cable length)
  • Number of nodes- Up to 256 nodes
  • Isolation- 2500 Vrms
  • Isolated RS485

  • Number of channels-1
  • Protocol- Modbus
  • Speed- 1.2bps- 115.2 kbps
  • Number of nodes-32
  • Isolation- 5kV rms
  • Standard Serial Interfaces

  • RS232- x 1 RS232 not isolated
  • USB- x 1 USB Host Connector
  • I2C- x 1 I2C interface
  • RTC

    RTC- Real time clock with Backup battery on board

    Expansion Connectors

    Expansion connector- Connector for direct interface to Mas Module products Smart Panel connector- Connector for smart panel (Character display and user Buttons for user interface)

    Electrical Specifications

  • Power supply- 9-48 VDC
  • Temperature- -40 + 85°C
  • Mechanical Specifications

    Dimensions- 156mm x 87mm

    Isolated Input

  • Number of input - 2
  • Type-Inverted digital logic
  • Thresholds-0-2,4V High; 2,5 - 24V
  • Low
  • Isolation - 3,75KV rms
  • Protection - 68 V DC
  • Isolated Output

  • Number of Output - 2
  • Type - Transistor Open Collector (without pull up)
  • Isolation - 3,75KV rms
  • Protection - 68 V DC
  • Non Isolated I/O

  • Number - 5
  • Type - Digital configurable Input and Output
  • Type of logi c- 3,3V TTL
  • I2C - x 1 I2C interface
  • Software Support

    Kernel Linux- For Fiamma Version: Kernel 3.14; For Ghita version kernel 3.17

    LAN

  • Number of ports- 1
  • Protocol- Modbus TCP; MQTT, TCP-IP
  • Speed- 10/100Mb/s
  • Connector type- RJ45
  • Isolation- 1500 Vrms
  • Wireless Interface- Wi-Fi/Bluetooth Module

  • Wi-Fi/BT- TiWi-BLE present on CPU board
  • IEEE 802.11 b.g.n
  • Full support for BT4.0 BLE and ANT
  • Bluetooth -2.1+EDR, Power Class 1.5
  • Wireless Interface- 3G/LTE (MU709S)

  • MU609
  • HSPA+/UMTS tri-band 850/1900/2100 MHz GSM/GPRS quad-band 850/900/1800/1900 Mhz Data Transfer Rate
  • Downlink:21.6 Mbps, Uplink: 5.76 Mbps
  • Wireless Interface- 3G/LTE (MU609)

  • MU609
  • HSPA+/UMTS quad-band 850/900/1900/2100 MHz GSM/GPRS quad-band 850/900/1800/1900 Mhz Data Transfer Rate
  • Downlink:14.4 Mbps, Uplink: 5.76 Mbps
  • Wireless Interface- 3G/LTE (MU909S)

  • LTE (FDD): B1,B3,B8 LTE (TDD): B38, B39,B40,B41DC-HSPA+/HSPA+/HSPA/UMTS: B1, B5, B8,B9 TD-SCDMA: B34, B39 EDGE/GPRS/GSM: 900/1800 MHz Data Transfer Rate
  • DC-HSPA+:Downlink:42 Mbps, Uplink: 5.76 Mbps
  • LTE TDD: Downlink:112Mbps, Uplink: 10Mbps
  • LTE FDD: Downlink:150 Mbps, Uplink: 50 Mbps @Bandwidth 20M
  • Wireless Interface- 3G/LTE (SIM)

    SIM Connector present on Board

    USB

    SPI, I2C

    QSPI0B

    i.MX6UL SoM- DORY

    i.MX6UL SoM- DORY

    Application Areas

    Industrial | Medical | Automation
