Ti Sitara based AM335x SBC - LIA - An Overview

AM335x SBC LIA offered from the proven Texas Instruments processor family ARM Cortex-A8@ 1GHz works well with industrial applications and accelerates power optimization in Embedded Systems. With common bus interfaces and display capabilities, AM335x SBC LIA extends support from Simple Gateways, PoS, Connected Vending Machines, Smart Toll Information Systems to more Intelligent Embedded Control Gateways & Authentication Devices. Embien’s Ti Sitara based AM335x SBC - LIA offers predictive maintenance and revolutionary computing capabilities for all AM335x based development platforms & helps improve the power/precision of a wide range of IoT Devices.

Specifications

CPU

  • CPU Name – MIREA Am335x Som
  • CPU Type – ARM® Cortex™-A8
  • Cores – x1
  • CPU Clock – up to 1GHz
  • PRU – The PRU and application software is available for AM3359
  • Memory

  • RAM – 512MB DDR3L
  • eMMC- From 4 to 64 GByte
  • NAND – 256/ 512 MByte
  • Display

    Parallel – RGB x1 16 bit

    Multimedia

    2D/3D graphic acceleration - x1

    Peripheral

  • SD / MMC- x1
  • USB Host/Device - x3 2 USB Host, 1x USB OTG
  • UART-x2
  • I2C-x2
  • SPI – x2
  • RTC – x1
  • Mini PCI Express- x1
  • Ethernet- x1 Gigabit
  • GPIOz - x30
  • Mechanical Specifications

    Dimensions (W x L x H)- 130×103.5 mm

    Electrical Specifications

  • Power Supply-12VDC
  • Consumption- 500mA
  • Environmental Specifications

  • Commercial Temperature Range (0 to 70°C) – Available
  • Extended Temperature Range (-20 to 70°C)- Available
  • Industrial Temperature Range(-40 to +85°C) - Available
  • Longevity

    Minimum availability – 2028

    Software Support

  • LINUX- Kernel 4.1.15 YOCTO
  • Android - Upon Request
  • Ubuntu - 18.04
  • USB

    SPI, I2C

    QSPI0B

    AM335x SoM - MIREA NET

    AM335x SoM - MIREA NET

    Application Areas

    Industrial | Medical | Automation
